How to use ExactFlat for efficiently producing insulation covers

Finding a simple digital pattern-making application is critical when migrating from traditional pattern-making. Making an industrial insulation blanket to fit current equipment is difficult and time-consuming, especially for beginners.

The big question is, how can you create insulating wraps in the shortest amount of time? More importantly, how do you save costs while doing so? ExactFlat is the most convenient way to produce digital patterns for all of your products. The ExactFlat program allows you to generate a pattern that fits perfectly on the first try in a fraction of the time.

Video Source

ExactFlat is a software that accurately handles various fabrication processes that were previously time-consuming and labor-intensive. It flattens the complex geometry of soft goods CAD models such as textiles, fabrics, furniture cushions, and more for cutting. Furthermore, it thoroughly examines the flattened design for stretch and sag to ensure that it fits the first time precisely.

The capacity to flatten insulation covers for pipework is an excellent demonstration of the software’s capability and flexibility. Pipe insulation involves accurately cutting insulation layers and precision placing fasteners and straps. Wrapping complex valves and pipelines can be challenging, but Exactflat makes it easy.
